Netherlands
28.3 cm/42.5 (11.1")
Updated 29 July 2007
Possibly manufactured by Krupp and used on a Coastal Defense Ship.  Overall length was 42.16 calibers and it appears that the actual bore length was 39.58 calibers.

De Zeven Provinciën
Institute for Maritime History Photograph

De Zeven Provinciën
Institute for Maritime History Photograph
.
Gun Characteristics
.
Designation 28.3 cm/42.5 (11.1")
Ship Class Used On Zeven Provinciën (later renamed Soerabaia)
Date Of Design N/A
Date In Service 1910
Gun Weight 33.5 tons (34 mt)
Gun Length oa 470 in (11.930 m)
Bore Length 441 in (11.201 m)
Rifling Length N/A
Grooves N/A
Lannds N/A
Twist N/A
Chamber Volume N/A
Rate Of Fire about 2 rounds per minute
.
Ammunition
.
Type Bag
Projectile Types and Weights AP - 666 lbs. (302 kg)
Bursting Charge N/A
Projectile Length N/A
Propellant Charge N/A
Muzzle Velocity 2,772 fps (845 mps)
Working Pressure N/A
Approximate Barrel Life N/A
Ammunition stowage per gun N/A
.
Range
.
Elevation With 666 lbs. (302 kg) AP Shell
Range @ 15 degrees 17,600 yards (16,100 m)
.
Mount / Turret Data
.
Designation Single Turrets
   Zeven Provinciën (2)
Weight  194.3 tons (197.4 mt)
Elevation -4 / +15 degrees
Elevation Rate N/A
Train about +120 / -120 degrees
Train Rate N/A
Gun recoil N/A
Loading Angle N/A
.
Data from
"Naval Weapons of World War Two" by John Campbell
"Battleships of World War I" by Peter Hore
